1405 D PRIME

STATIONARY CONCRETE PUMP – 1405 D PRIME

OVERVIEW

The Aquarius 1405 D PRIME Stationary Concrete Pump, manufactured by Aquarius Engineers Pvt. Ltd., is a diesel-powered concrete pumping solution designed for efficient and reliable concrete placement in construction applications. Equipped with a 49 kW prime mover, the pump delivers a theoretical output of 51/35 m³/hr and concrete pressure of 61/91 bar, depending on the hydraulic operating configuration. Its sturdy trailer frame with four outriggers provides stability during pumping operations, while the mechanical override system supports operational continuity. The optimized pumping mechanism features a lower number of strokes in its class, helping reduce wear-part costs and maintenance requirements. With a horizontal delivery distance of up to 500 metres or a vertical delivery distance of up to 125 metres, the Aquarius 1405 D PRIME provides a practical solution for concrete conveying requirements in building and infrastructure construction.

KEY FEATURES

  • High Concrete Output: Delivers a theoretical pumping capacity of up to 51 m³/hr..
  • High-Pressure Performance: Provides concrete pressure of up to 91 bar.
  • Diesel-Powered Operation: Equipped with a 49 kW prime mover for concrete pumping applications
  • Stable Trailer Structure: Sturdy and rigid trailer frame with four outriggers ensures stability during pumping operations.
  • Reduced Wear-Part Costs: Lower stroke frequency in its class helps minimize wear-part expenses
  • Extended Maintenance Intervals: Highly reliable equipment designed for longer maintenance intervals.
  • Mechanical Override System: Enables continued operation through mechanical override of the electrical system.
  • Long-Distance Concrete Delivery: Supports horizontal pumping up to 500 metres or vertical pumping up to 125 metres.
  • Modern Equipment Design: Features a futuristic appearance with an updated machine design.

TECHNICAL SPECIFICATION

Model: 1405 D PRIME

Pump Type: Stationary Concrete Pump

Drive : Diesel

Prime Mover:  49 kW

Theoretical Output: 51 / 35 m³/hr

Delivery Cylinder Diameter: 200 mm

Delivery Cylinder Stroke: 1400 mm

No. of Strokes: 19 / 12 per min

Hydraulic Transmission:

Road Side: 1:4.9

Head Side: 1:3.3

Concrete Pressure: 61 / 91 bar

Concrete Hopper Capacity: 600 L

Delivery Distance:

Horizontal: 500 m

Vertical: 125 m

*Values for hydraulic fluid being fed to piston side.

**Distances to be read as either horizontal or vertical. The concrete should be pumpable & follows

DIN 1405 standard.

ADDITIONAL FEATURES

  • Concrete Feeding System: Equipped with a 600-litre concrete hopper to support concrete feeding during pumping operations.
  • Delivery Cylinder Configuration: Features a 200 mm diameter delivery cylinder with a 1400 mm stroke.
  • Hydraulic Transmission System: Incorporates rod-side and head-side hydraulic transmission configurations.
  • Flexible Concrete Conveying: Supports both horizontal and vertical concrete delivery through suitable pipeline arrangements.
  • Flexible Concrete Conveying: Supports both horizontal and vertical concrete delivery through suitable pipeline arrangements.
